HP Gaming 690-0022na DT Core i5-8400 8GB 2TB+16GB SSD 4GB GTX1050Ti DVDRW WiFi W10 - 4DU53EA
The HP Pavilion Gaming Desktop is all about smooth performance and crisp graphics wrapped up in a bold design. This PC offers the latest technology plus the ability to upgrade, keeping performance up-to-date. Get ready to play in powerful style today and for years to come.
mpn | 4DU53EA |
---|---|
Processor | Core i5 |
Harddrive Size | 2TB |
gpu | GTX 1050TI |
Processor
Processor family | Intel® Core™ i5 |
---|---|
Processor manufacturer | Intel |
Processor model | 8400 |
Processor frequency | 2.8 GHz |
Processor generation | 8th gen Intel® Core™ i5 |
Processor cores | 6 |
Processor boost frequency | 4 GHz |
Processor socket | LGA 1151 (Socket H4) |
Processor cache | 9 MB |
Processor cache type | Smart Cache |
Processor threads | 6 |
System bus rate | 8 GT/s |
Bus type | DMI3 |
Processor lithography | 14 nm |
Processor operating modes | 64-bit |
Processor codename | Coffee Lake |
Thermal Design Power (TDP) | 65 W |
Tjunction | 100 °C |
PCI Express slots version | 3.0 |
Maximum number of PCI Express lanes | 16 |
PCI Express configurations | 1x16, 1x8+2x4, 2x8 |
Number of processors installed | 1 |
Maximum internal memory supported by processor | 64 GB |
Memory types supported by processor | DDR4-SDRAM |
Memory clock speeds supported by processor | 2666 MHz |
Memory bandwidth supported by processor (max) | 41.6 GB/s |
ECC supported by processor |
Memory
Internal memory | 8 GB |
---|---|
Internal memory type | DDR4-SDRAM |
Memory layout (slots x size) | 1 x 8 GB |
Memory clock speed | 2666 MHz |
ECC | |
Memory channels | Dual-channel |
Storage
Total storage capacity | 2 TB |
---|---|
Optical drive type | DVD-RW |
Storage media | HDD |
Number of storage drives installed | 1 |
Total HDDs capacity | 2 TB |
Number of HDDs installed | 1 |
HDD capacity | 2 TB |
HDD interface | SATA |
HDD speed | 7200 RPM |
Card reader integrated | |
Intel® Optane™ Memory module installed | |
Intel® Optane™ Memory module capacity | 16 GB |
Graphics
Discrete graphics card | |
---|---|
On-board graphics card | |
Discrete graphics card model | NVIDIA® GeForce® GTX 1050 Ti |
On-board graphics card model | Intel® UHD Graphics 630 |
Discrete GPU manufacturer | NVIDIA |
Discrete graphics memory type | GDDR5 |
Discrete graphics card memory | 4 GB |
Number of discrete graphics cards | 1 |
On-board graphics card base frequency | 350 MHz |
On-board graphics card dynamic frequency (max) | 1050 MHz |
Maximum on-board graphics card memory | 64 GB |
Number of displays supported (on-board graphics) | 3 |
On-board graphics card DirectX version | 12.0 |
On-board graphics card OpenGL version | 4.5 |
On-board graphics card ID | 0x3E92 |
Number of execution units | 23 |
Network
Ethernet LAN | |
---|---|
Wi-Fi | |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Cabling technology | 10/100/1000Base-T(X) |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Bluetooth | |
Bluetooth version | 4.2 |
Ports & interfaces
USB 2.0 ports quantity | 2 |
---|---|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
HDMI ports quantity | 1 |
DVI port | |
HDMI version | 2.0 |
DisplayPorts quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Microphone in | |
Line-out | |
Line-in | |
Combo headphone/mic port |
Expansion slots
PCI Express x1 slots | 1 |
---|---|
PCI Express x16 slots | 1 |
Design
Chassis type | Mini Tower |
---|---|
Product colour | Black |
Placement supported | Vertical |
Country of origin | China |
Performance
Product type | PC |
---|---|
Market positioning | Gaming |
Motherboard chipset | Intel® H370 |
Audio output channels | 5.1 channels |
Software
Operating system installed | Windows 10 Home |
---|---|
Operating system architecture | 64-bit |
Pre-installed software | Netflix |
Trial software | McAfee LiveSafe, Microsoft Office 365 |
Bundled software | Dropbox |
Processor special features
Intel 64 | |
---|---|
Enhanced Intel SpeedStep Technology | |
Embedded options available | |
Intel® InTru™ 3D Technology | |
Intel® Clear Video HD Technology (Intel® CVT HD) | |
Intel Clear Video Technology | |
Intel VT-x with Extended Page Tables (EPT) | |
Intel TSX-NI | |
Idle States | |
Thermal Monitoring Technologies | |
Intel Stable Image Platform Program (SIPP) | |
Intel® AES New Instructions (Intel® AES-NI) | |
Intel® Secure Key | |
Intel® OS Guard | |
Intel Trusted Execution Technology | |
Execute Disable Bit | |
Intel Enhanced Halt State | |
Intel Software Guard Extensions (Intel SGX) | |
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | |
Processor package size | 37.5 x 37.5 mm |
Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
Scalability | 1S |
CPU configuration (max) | 1 |
Thermal solution specification | PCG 2015C |
Intel Virtualization Technology for Directed I/O (VT-d) | |
Intel Identity Protection Technology version | 1.00 |
Intel Stable Image Platform Program (SIPP) version | 0.00 |
Intel Secure Key Technology version | 1.00 |
Intel Virtualization Technology (VT-x) | |
Intel TSX-NI version | 0.00 |
Processor ARK ID | 126687 |
Intel® Optane™ Memory Ready | |
Intel® Turbo Boost Technology | 2.0 |
Intel® Hyper Threading Technology (Intel® HT Technology) | |
Intel® Quick Sync Video Technology | |
Intel® Identity Protection Technology (Intel® IPT) | |
Conflict-Free processor |
Brand-specific features
HP JumpStart | |
---|---|
HP Software provided | HP Lighting Bar Control |
Power
Power supply | 310 W |
---|
Sustainability
Sustainability certificates | EPEAT Silver, ENERGY STAR |
---|
Weight & dimensions
Width | 170 mm |
---|---|
Depth | 277 mm |
Height | 338 mm |
Weight | 5.15 kg |
Package width | 390 mm |
Package depth | 499 mm |
Package height | 291 mm |
Package weight | 8 kg |
Packaging content
Display included |
---|
Other features
Optical drives quantity | 1 |
---|
Powerful graphics
Get lost in fluid gameplay and smooth visuals. With up to NVIDIA® GeForce® GTX 1060 or AMD® Radeon™ RX 580 discrete graphics, lag and slowdowns are a thing of the past.High-speed performance
Unleash the full potential of your PC with an either an Intel® Core™ processor[1] or an AMD® Ryzen™ processor[1] and up to 16 GB of DDR4 RAM.Bold, standout design
With a distinct angular bezel, brushed finishing, and green LED lighting this desktop is built to make a statement. To complement it all, interior expansion slots let you upgrade your graphics card, memory, and more to keep performance up-to-date.Windows 10
Do great things confidently with the familiar feel of Windows - only better.[1]8th Generation Intel® Core™ processor
Upgrade performance with smooth system responsiveness and fast load times for an exceptional PC experience. Supporting resolution up to stunning 4K, stream premium content or even create your own.[2]NVIDIA® GeForce® GTX 1050 Ti graphics
Give your biggest, graphically demanding projects and multimedia experiences a boost in detail with 1080p and game without experiencing any slowdowns, hiccups, or stuttering.[2]Rock-solid connections
Never worry about spotty Internet and weak connections. Stay powerfully connected to Wi-Fi and to Bluetooth® accessories with the latest 802.11 a/c (2x2) WLAN adapter and Bluetooth® 4.2.[3]Re-writable DVD drive
Watch and write DVDs using the integrated optical drive.[4]DDR4 RAM options
Designed to run more efficiently and more reliably at faster speeds, DDR4 is the future of RAM. With its higher bandwidth, everything from multi-tasking to playing games gets a performance boost.Hard drive storage
Don’t worry about growing your collection of digital movies, songs, and pictures. With massive storage options you can save it all, and still have plenty of room left over.5.1 Surround Sound output
With all the necessary ports for true 5.1 surround sound, give your favorite movies, shows, or music more nuanced, immersive sound quality, just by hooking up a Surround Sound speaker setup.USB-C™
Transfer data at high speeds to or from your external storage with this USB-C™ port. And it’s reversible, so you never have to worry about plugging in upside down.[19,20]VR ready
We’ve stressed the hardware and drivers with the most intensive games to ensure rock-solid performance and high-definition graphics, for a smooth VR experience right out of the box.[21]HP Jumpstart
When you boot up your PC for the first time, get a personal walkthrough during the setup and get an informative overview of your PC’s features.Dropbox cloud storage
Store and synchronize your content online with Dropbox. Get 25GB of storage for one year to access, manage, and share your photos, music, and files from anywhere with Internet access.[22]This is a HP Certified Renew Product = HP Certified Quality
HP Renew products are guaranteed to be exactly the same condition and quality as a brand new product. All HP Renew products undergo a complete HP remanufacturing and testing process, fully restoring them to meet HP certified standards. HP sets strict quality standards for its entire technology portfolio, and ensures that remanufactured products offer the same performance and reliability as new products.
These items are delivered in a brown HP box and come with a UK power cord. Most desktops come with a keyboard and mouse set however if the set supplied by HP is a European keyboard they will be provided with a generic brand UK replacement set.
Full HP Warranty
HP Renew products are covered by the exact same warranty that is offered with new retail HP products. These products are only given the full original warranty after passing HP's stringent quality tests, guaranteeing HP quality and reliability. Additional service and support options are also available to complement the original HP product warranty.
Great Value for Money
HP Renew products offer the same reliability and performance as new HP products, but for at least 10% less than the cost of the equivalent new product. If you have a limited IT budget, HP Renew is the perfect alternative – high quality solutions at a lower cost.
This unit has a full one year manufacturer's warranty from date of purchase.
